MTP-12 UPC(Female) to MTP-12 UPC(Female), 12Fibers, Multimode (OM5),OFNP, Lime Green, Type B
This MTP-12 UPC (Female) to MTP-12 UPC (Female) OM5 trunk cable is built around the US Conec MTP® connector, the industry-leading MPO-style interface widely used in high-density data center cabling. By combining a precision MTP® ferrule interface with OM5 wideband multimode fiber (WBMMF) y un OFNP plenum-rated jacket, this assembly is designed for dependable performance in modern backbone, cross-connect, and leaf-spine architectures.
Why US Conec MTP® matters
US Conec’s MTP® is not just an “MPO-compatible” connector—it is a premium interface engineered for better mechanical stability, repeatable mating, and scalable density in patch panels and cassette systems. In real deployments, that translates to more consistent connections when you’re managing multiple trunks, frequent patching, and space-constrained racks.
OM5: wideband multimode designed for higher-speed optics
OM5 is a wideband multimode fiber optimized for shortwave wavelength division multiplexing (SWDM) and next-generation multimode optics. Compared with traditional OM3/OM4, OM5 is designed to support multiple wavelengths in the 850–950 nm range, enabling higher capacity over the same fiber count—helping data centers scale bandwidth without multiplying trunk quantity.
Feturas
US Conec MTP® connectors: premium MPO-style interface for high-density connectivity
MTP-12 UPC Female to Female, 12 fibers
OM5 wideband multimode (WBMMF) for bandwidth scaling and SWDM readiness
OFNP (plenum-rated) jacket for in-building plenum installations
Type B polarity for structured cabling and cassette-based systems
Lime green jacket color for quick OM5 identification
Suitable for 40G/100G/200G SR multimode interconnects (based on your transceiver/system design)
Especificaciones técnicas
Connector Brand | US Conec MTP® Elite Female (Non-Pinned) |
Conector A | MTP 12F Female |
| Conector B | MTP 12F Female |
| Polaridad | Type B |
| Polish Type | UPC to UPC |
| Insertion Loss (dB) @850&1300nm | Typical<0.15, Max.<0.35 |
Pérdida de retorno (dB) | >25 |
Modo fibra | OM5 50/125μm |
Recuento de fibras | 12 Fibers |
Cable Outside Diameter | 3,0 mm |
Cubierta del cable | Plenum (OFNP) |
Cable Retention | 80N (0 degrees) |
Temperatura de funcionamiento | -10～+60 ℃ |
Aplicación
Data center backbone and cross-connect cabling
MTP/MPO patch panels, rack panels, and high-density fiber enclosures
Leaf-spine architecture interconnects (switch-to-switch links)
40G/100G/200G multimode SR deployments (system-dependent)
SWDM-capable multimode links where OM5’s wideband performance adds upgrade flexibility
Enterprise building plenum cabling (OFNP requirement)
